The D-Link DSL-2730B Router supports WPS (Wi-Fi Protected Setup). WPS is a standard for easy and secure wireless network establishment. With WPS you can configure and secure your wireless network in just a few easy steps. The WPS button is located on the right side of the router. Press the button to activate the WPS feature. The light blinks when WPS is activated successfully. When the connection is established successfully between the router and the client, the blue light will be solid and will remain for five seconds. Once the light is off, the Router is ready to set up a new WPS connection. To use WPS router, you need to have WPS-compatible wireless clients. If you have 1 or more wireless clients without support WPS, is recommended to protect your network manually through the Setup Wizard.

This section will guide you through the installation process. The placement of the router is very important. Do not place the Router in an enclosed area such as a closet, Cabinet, or in the attic or garage. Read and understand all the prerequisites for the proper installation of your new router. Have on hand the information and equipment necessary before beginning installation. To establish a connection to the Internet you will need to provide information to the Router that will be stored in its memory. Your account (username and password) information is only required for some users. Others will require different parameters that control and define the connection to the Internet. You can print the following two pages and use the tables to list this information. In this way, you have a hard copy of all the information necessary to configure the router. If it is necessary to reset the device, you can easy access to all the necessary information.

Be sure to keep this information secure and private. Since ADSL and telephone services share the same copper wiring to carry their respective signals, a filtering mechanism may be necessary to avoid mutual interference. You can install a device of pass filter bass for each phone that shares the line with the ADSL line. These filters are easy to install passive devices that are connected to the ADSL device and/or telephone using a standard telephone cable. Ask your service provider for more information on the use of filters low with your installation. The DSL-2730B uses a web interface HTML-based configuration and management. You can access the Web Configuration Manager using any operating system capable of running software from the web browser, including Windows 98 SE, Windows ME, Windows 2000, Windows XP and Windows Vista.

802.11n Wireless ADSL/ADSL2/2+ Modem Router
The DSL-2740B Wireless N 300 ADSL2+ Modem Router is a versatile, high-performance remote router for the home and small office. With integrated ADSL2/2+ supporting up to 24Mbps download speeds, firewall protection, Quality of Service (QoS), 802.11n wireless LAN and 4 Ethernet switch ports, this router provides all the functions that a home or small office needs to establish a secure and high-speed link to the Internet.
Ultimate Wireless Connection with Maximal Security
Powered by Wireless N technology, this router provides wireless speeds that are up to 4 times faster than 802.11g*. Maximize wireless performance by connecting this router to computers equipped with Wireless N wireless interfaces and stay connected from virtually anywhere at home and in the office. The router can also be used with 802.11g and 802.11b wireless networks to enable significantly improved reception. It supports WPA/WPA2 and WEP for flexible user access security and data encryption methods.
Firewall Protection
The router provides firewall security using Stateful Packet Inspection (SPI) and hacker attack logging for Denial of Service (DoS) attack protection. SPI inspects the contents of all incoming packet headers before deciding which packets are allowed to pass through. Access control is provided with packet filtering based on port and source/destination MAC/IP addresses. With Virtual Server Mapping, only specific services on a local server, like web, FTP or games may be made accessible from the Internet, ensuring the rest of the machine remains protected from hackers. VPN pass-through is provided to let mobile users securely access office files and mail from home.
Quality of Service Features
The DSL-2740B supports multiple priority queues to enable a group of home or office users to experience smooth connectivity without suffering the effects of network congestion. This support for Quality of Service (QoS) allows you to enjoy lag-free transmission for applications such as VoIP and streaming multimedia over the Internet.
* Maximum wireless signal rate derived from IEEE standard 802.11g and 802.11n specifications. 802.11n speeds obtainable when operating with Wireless N products. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction may lower actual data throughput rate. Environmental factors may adversely affect wireless signal range. Wireless N products are based on IEEE 802.11n specifications. All references to speed are for comparison purposes only.
